165C10D Loren Cook Direct Drive Exhaust Fan 115/60/1

$2,145.51

PRICE INCLUDES FREIGHT

Base: 24″ Square

Motor: 1/3 HP 115 volt / 1 phase

CFM Range:  2935 CFM @ 0″ to 1902 CFM @ .75″ static pressure

Wheel Diameter- 16.5″

Fan RPM-1050

Tip speed- 4644

Loren Cook Model #: 165C10D

REPLACEMENT MOTOR: 100172 Loren Cook Direct Drive Replacement Motor

REPLACEMENT BLADE: 705338 165 Series Direct Drive Loren Cook Replacement Wheel

REPLACEMENT TOPCAP/LID: email support@allaroundindustrysupply.com

Subtotal:

Add-ons total:

Total:

Category:

Description

PRICE INCLUDES FREIGHT

Base: 24″ Square

Motor: 1/3 HP 115 volt / 1 phase

CFM Range:  2935 CFM @ 0″ to 1902 CFM @ .75″ static pressure

Wheel Diameter- 16.5″

Fan RPM-1050

Tip speed- 4644

Loren Cook Model #: 165C10D



Dimension drawing

Fan Size A B C D T Sq. Roof Opening for
curbs supplied by LOREN COOK COMPANY.
Approximate
Shipping Weight
(pounds)
70 1-3/4 13-5/8 13-13/16 2 18 13-1/2 20
90 2-1/2 18-3/4 16-13/16 2 18 13-1/2 28
100 2-1/2 18-3/4 16-13/16 2 18 13-1/2 30
101 2-3/8 23-9/16 21-1/8 2 18 13-1/2 30
120 1-7/16 28-7/16 26-9/16 2 20 15-1/2 67
135 1-15/16 28-7/16 27-1/16 2 20 15-1/2 72
150 2/13/16 32-7/8 28-11/16 2 24 19-1/2 87
165 3-5/16 32-7/8 29-3/16 2 24 19-1/2 90
180 3-5/16 37-11/16 33-15/16 3 30 25-1/2 102

Installation Manual - Please email support@allaroundindustrysupply.com or fill our contact information below and we will contact you shortly.

Replacement Motor for this fan - 100172 ($125.00 Delivered) Loren Cook Direct Drive Replacement Motor

Replacement Wheel for this fan - 705338 ($455.00 Delivered) 165 Series Direct Drive Loren Cook Replacement Wheel

Spec Sheet - Please email - support@allaroundindustrysupply.com or fill our contact information below and we will contact you shortly.



Dimension drawing

Fan Size A B C D T Sq. Roof Opening for
curbs supplied by LOREN COOK COMPANY.
Approximate
Shipping Weight
(pounds)
70 1-3/4 13-5/8 13-13/16 2 18 13-1/2 20
90 2-1/2 18-3/4 16-13/16 2 18 13-1/2 28
100 2-1/2 18-3/4 16-13/16 2 18 13-1/2 30
101 2-3/8 23-9/16 21-1/8 2 18 13-1/2 30
120 1-7/16 28-7/16 26-9/16 2 20 15-1/2 67
135 1-15/16 28-7/16 27-1/16 2 20 15-1/2 72
150 2/13/16 32-7/8 28-11/16 2 24 19-1/2 87
165 3-5/16 32-7/8 29-3/16 2 24 19-1/2 90
180 3-5/16 37-11/16 33-15/16 3 30 25-1/2 102

All fans include a one year warranty. Must have certification or license to install electrical components and products. All information, and proven certifications must be emailed to support@allaroundindustrysupply.com Warranty does not cover freight, damages to outside parts, components, or ramifications of defective parts external to the fan. Warranty does not cover labor or additional cost associated with installation, repair, or injury.
